NEW LC100-A Digital LCD High Precision Inductance Capacitance L/

Brand New High Quality
modle:LC100-A
Size: 81 x 47 x 30 mm ( L*W*H )
Supply power: +5v ,mini USB interface
Measurement accuracy:1%
Capacitance measuring range: 0.01 pF - 10uF
The minimum resolution: 0.01 pF
Big Capacitance measuring range ：1uF-100mF/minimum resolution:0.01UF
Inductance measuring range: 0.001 uH - 100mH
Big inductance measuring range: 0.001 mH - 100H
The minimum resolution: 0.001uH
Test frequency range: L/C about 500KHZ/Big inductance 500HZ
Effective display digits: 4 digits
LCD display mode: 1602

Note:
When measuring the frequency of the inductance or Capacitance, please press the black button, as the PIC shows.
Please reset to zero, before testing a Capacitance or inductance, or it may damage the board.
If the result on the LCD is not stable, it s normal due to the poor quality of L/C.

Package include:
1x High Precision L/C Meter Board LC100-A
1x Mini USB Cable for Power Supply
