New Genius G540 USB Universal Bios GAL Programmer EPROM FLASH 51

New Genius G540 USB Universal Bios GAL Programmer EPROM FLASH 51 AVR PIC MCU SPI
100% Brand New And High Quality
1,40-Pin ZIF socket.
2, USB communication. USB powered, no external power supply. Is very convenient to use.
3, the software is compatible with Windows2K/XP/Vista.
Software version V5.00, compared with 4.11 version:
1), to solve a problem loading the file;
2), solve the PIC16F73, 77. . . 93CXXX other error problem;
3), added PIC18FXXX family support;
4), added the PIC series with the load the hex file is automatically loaded configuration information functions.
5), added Winbond W25Xxxx, and many other 8pin EEPROM, Flash support for a total of more than 6500 kinds of details of the IC to download G540Device_List
4, system software upgrades. In the context supported by the hardware, the user for life
Access to the latest version of software upgrades, without firmware limitations. Users
Only need to download the latest version of the software, you can complete the upgrade.
5, supporting up to more than 6,000 kinds of IC of the burn, and continue to add.
6, pin-contact detection accuracy. The event of poor contact or insertion release error
Promptly terminate the operation. (Very small number of devices such as the PIC16C54,
AT24C01 ... ..., may not achieve pin-contact detection)
7, the operation results of re-instruction: software interface shows that light flashing instructions.
8, pocket-sized compact exterior design. Beautiful and generous, with the convenience of portability.
9, low-cost high-performance program. For the sake of putting ourselves in the user.
10, a good self-protection methods. An effective guarantee against damage to a user or programmer IC itself.
Condition: Brand New and High Quality G540 USB universal programmer
Product Name :G540 Universal Programmer
Color: Blue
Size (mm): 145 x 110 x 24mm
COM USB:1.1/2.0
Power USB :5V or Power Cable
Current: Min 70mA/ Max 500mA
Connect :2M
Software :G540 VER5.XX(Support Windows XP/Vista/Win 7(32-bit))
Look at the following link of supporting device list:
stg51.com/down/html/?59.html
Package includes:
1x G540 programmer
1x USB cable
1x Install software CD
1x user manual (paper document)
1x PLCC32-DIP32 socket adapter
1x PLCC44 TO DIP40 adapter
1x PLCC IC extractor
We can also wholesale if you need a large quantity of item please contact us
