High power Motor Driver Module H-Bridge Control 3-25V 90A For Smart Car Robot
Demo video：
http://static.youku.com/v1.0.0134/v/swf/qplayer.swf?VideoIDS=XMzYxOTk4NTUy&embedid=&isAutoPlay=true&embedid
OUT1: Dc motor positive
VCC: Motor driver positive
GND: Motor driver negative
OUT2: Dc motor negative
+5V: Power +
GND: Power -
IN1: Motor input control interface 1
IN2: Motor input control interface 2
EN: Motor driver PWM control interface
100% Brand New And High Quality
high-power motor drive modules are designed for small high-power DC motor design
Driver chip control signals are opto-isolation circuit for effective protection of the microcontroller
The driver chip using MOS transistor drive motor
Low internal resistance
Motor drive module uses H-bridge circuit, you can control the motor, reverse
Control circuit is simple, only three control lines
The small size of the motor drive module
Specification:
Operating voltage: 3 V-25V
Operating frequency: 0-40KHZ
Drive current: Peak 90 A (amps)
Drive type: MOSFET
On-state resistance: 5.7mΩ (milliohms)
Module size: 41mm * 33mm
PWM duty cycle: 0 ~ 98%
Package includes:
1 x high-power H-bridge Driver
