DC 0-300V 500A Dual LED Digital Volt Amp Voltage Power Meter + 500A/75mV Shunt
100% Brand New And High Quality
2 in 1 function Voltmeter Ammeter, Easy install.
This meter test of Voltages and Amps, power supply can taken from the test circle, no additional power supply
Power supply DC 4.5V - 30V range (Attention: The maximum of input voltage cannot be exceed of 30V, otherwise would be burnt)
Display Range: DC 0V - 300V 0-500A (Please don't exceed the range)
Measuring Range: DC 0V - 300V (Resolution: 1V)
Current: 500A
Resolution: 1A
Display: 0.28" LED digital tube
LED Color : Red Color on Voltmeter and Blue on Ampmeter
Large, high-visibility
Low Power Consumption
Operating Current: less than 60mA
Resolution ±1%+1 digit
Measurement rate: ≥ 500mS / times
Operating Humidity: 10 to 80% (non-condensing)
Operating temperature -10~65 Deg
Operating Pressure: 80 ~ 106kPa
Size: 48x29x21 mm
Panel cutout 45.5x26.5 mm
Package includes:
1 x DC 300V 500A Dual LED Digital Volt Amp Voltage Power Meter
1 x 1 X 500A/75mV Shunt
We can also wholesale if you need a large quantity of item please contact us
