CMOS Camera Module OV7670 Display Active Size 640X480

100% Brand New
High sensitivity for low-light operation.
Low operating voltage for embedded portable apps.
Automatic image control functions including:AEC,AGC,AWB,ABF,and ABLCImage quality controls including color saturation, hue,gamma,sharpness(edge enhancement),and anti-blooming.
ISP includes noise reduction and defect correction.
Supports led and flash strobe mode.
Supports scaling.
Lens shading correction.
Flicker(50/60Hz) auto detection.
Edge enhancement level auto adjust.
De-noise level auto adjust.
Size: 23MM X 21MM
Specifications:
IO voltage of 2.5V to 3.0V (internal LDO for nuclear power 1.8V)
Power operation 60mW/15fps VGA YUV
Sleep <20μA
Operating temperature -30 ℃ to 70 ℃
Stability 0 ℃ to 50 ℃
Output format (8) YUV/YCbCr4: 2:2 RGB565/555/444 GRB4: 2:2 Raw RGB Data
Optical Size 1 / 6 "
Angle 25 °
Maximum rate of 30fps VGA Chen
Sensitivity 1.3V / (Lux-sec)
SNR 46 dB
52 dB dynamic range
View Mode Progressive
E-1 line to 510 line exposure
Pixel size 3.6 μm x 3.6 μm

Package included:
1 x CMOS Camera Module OV7670
