ATMEL AVR ATMEGA128 Mega128 Development Board Kit New

AVR mega128 Starter Development Board provides easy way for developing with the new mega128/mega 128L/mega128A high-performance, microcontroller produced by ATMEL.AVR mega128 Starter Development Board has ISP and JTAG port for programming and debugging, 2 UART, 8 status Leds, 8 user Buttons,DS1302 circuit,DS18B20 circuit, buzzer circuit, EEPROM circuit,8bits 7-SEG display controlcircuit,LCD1602,LCD12864 PORT,INT0&INT1,stepmotor port, servo port and all of the GPIOs are taken out to make them available for further connections. AVR mega128 Starter Development Board gives designers a quick start to develop code on the AVR, combined with features for developing prototypes and testing new designs.

Area

Description

Area

Description

1

6-12V Power Input

17

LCD12864’s P/S Communication Mode Setting Jumper[*]

2

USB Power Input

18

LCD1602 & LCD12864 Contrast Potentiometers

3

Power Led

19

Servo0 & Servo1 Ports

4

Power Switch

20

ULN2003A Input Signal Jumper

5

5V/3.3V Selection Jumper

21

Step motor Port

6

UART0 & UART1 Ports

22

Buzzer

7

ISP Programming Port

23

LEDs Enable & DS18B20 Jumper

8

JTAG Debugging Port

24

8 LEDs

9

ADC0 & ADC1 Input Jumper

25

DS18B20

10

ADC0 & ADC1 Potentiometers

26

INT0 & INT1 Jumper

11

DS1302,MAX232 and 24CX Jumper

27

INT0 & INT1 keys

12

8 User keys

28

8-BITs-7-seg Display Jumper

13

System Reset Button

29

8-BITs-7-seg Display

14

System Clock (External Clock)

30

DS1302

15

Mega128 core with pinouts

31

MAX232

16

LCD1602 & LCD12864 Ports

32

24CX

Pckage include:
1x development board with Atemega128
1x USB powr cable
1x CD ROM including Board Schematic , Sample code software ,demo,etc
