5 pcs DHT11 DHT-11 Digital Humidity Temperature Sensor New

5 pcs DHT11 DHT-11 Digital Humidity Temperature Sensor New
DHT11 digital temperature and humidity sensor is a digital signal output with a calibrated temperature and humidity combined sensor. It uses a dedicated digital modules and acquisition of temperature and humidity sensor technology to ensure that products with high reliability and excellent long term stability. Sensor consists of a resistive element and a sense of wet NTC temperature measurement devices, and with a high-performance 8-bit microcontroller connected. Therefore, the product has excellent quality, fast response, anti-interference ability, high cost and other advantages. Each DHT11 sensors are extremely accurate calibration of humidity calibration chamber. Calibration coefficients stored in the OTP program memory, internal sensor, signal processing in the detection process to call these calibration coefficients. Single-wire serial interface, allowing the system to become simpler and quicker integration. Ultra-small size, low power consumption, signal transmission distance up to 20 meters, making it a wide range of applications and even the most demanding applications is the best choice. Product is 4-pin single-row pin package. Easy connection, special packages can be provided according to user needs.Technical Specification:Power supply: 3-5.5V DC
Output signal: digital signal via single-bus
Operating range: humidity 20-90%RH, temperature 0-50Celsius
Accuracy: humidity +-4%RH(Max +-5%RH) , temperature +-1Celsius
Resolution: humidity 1%RH, temperature 1Celsius
Repeatability: humidity +-1%RH, temperature +-1Celsius
Response time: Average:10s ( Max15s)
Humidity hysteresis:+-1%RH
Stability: +-1%RH/Year
Interchangeability: fully interchangeable
Dimensions: 12*15.5*5.5mmApplications:HVAC
Testing and inspection equipment
Automotive
Data logger
Consumer goods
Automatic control
Weather Station
Home Appliances
Humidity Regulator
Medical
DehumidifierPacking Included:5pcs DHT11Sensor
